AIR COMPRESSOR

Model AS04 – AS110
Capacity 0.58 m³/min – 20.1 m³/min
Pressure AS04-AS15 : 8.0 10.0 13.0 barg
AS18-AS110: 7.6 8.6 10.6 12.6 barg
Power 04 kW – 110 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor ODP

Model WS18 – WS75
Capacity 2.2 m³/min – 14.7 m³/min
Pressure 7.6 8.6 10.6 12.6 barg
Power 18 kW – 75 kW (25HP-100HP)
Electrical 380 Volt / 3 Phase / 50 Hz
Motor TEFC

Model LS20-125 – LS32S-600
Capacity 12.9 m³/min – 80.1 m³/min
Pressure 5.5 7.5 8.5 10.5 13 barg
Power 90 kW – 350 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor ODP / TEFC
Option Variable Speed Drive

Model TS20-125 – TS32S-600
Capacity 12.9 m³/min – 80.1 m³/min
Pressure 5.5 7.5 8.5 10.5 13 barg
Power 90 kW – 350 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor ODP / TEFC
Option Variable Speed Drive

Model PM22 – PM37
Capacity 0.55 m³/min – 12.35 m³/min
Pressure 7 8 10 barg
Power 22 kW – 37 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor IE4 TEFC IP55 with variable speed
Option Air Cooled

Model DS75 – DS250
Capacity 13.1 m³/min – 22.1 m³/min
Pressure 7.5 8.5 10.5 13 barg
Power 75 kW – 250 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor ODP / TEFC
Option Air Cooled / Water Cooled / VSD

Model GS15VSD – GS75VSD
Capacity 0.55 m³/min – 12.35 m³/min
Pressure 5.5 7.5 8.5 10.3 barg
Power 15 kW – 75 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor TEFC IP55 with Variable Speed
Option Air Cooled / Water Cooled

Model SRL(VT)
Capacity 0.16 m³/min – 3.78 m³/min
Pressure 6.5 – 8.5 barg
Power 1.5 kW – 33 kW
Electrical 380 Volt / 3 Phase / 50 Hz
Motor TEFC IP55 with Variable Speed
Option Air Cooled

Model 185 – 1600
Capacity 8.6 m³/min – 45.1 m³/min
Output Pressure 100, 125, 150, 400 psi
Power 224 kW – 540 HP
Diesel Engines Dongfeng Cummin, Caterpillar
Mounting Options DPQ, DLQ, DWQ, DL

Model 550 – 1000
Capacity 550 – 1050 cfm
Output Pressure 135 – 195 psi
Power 132 kW – 195 kW
Mounting Options ETQ or ELQ

Armstrong reciprocating compressor family has earned worldwide recognition via a proven design and stellar track record. Reliable – trustworthy – money saving – enhanced business success through:

  • Lower life cycle costs
  • Ability to thrive in punishing applications
  • Configurations that meet varying needs
  • Optimum solutions for greater efficiency

AIR TREATMENT

Sullair SRCG

Capacity 1 – 180 m³/min
Max/min inlet Pressure 16 barg/3 barg
Max/min inlet Temp 49°C / 4°C
Pressure Dew Point 3°C
Standard Rate Condition 42°C inlet temp,
38°C ambient air temp, 7.0 barG inlet pressure

Hankison PCM

Capacity 2. 8-16.5 m³/min
Max/min inlet Pressure 16 barg/3 barg
Max/min inlet Temp 65°C / 4°C
Pressure Dew Point 3°C
Standard Rate Condition 50°C inlet temp,
35 °C ambient air temp, 7.0 barG inlet pressure

Pure Air PALF


Capacity 0.6 – 65 m³/min
Max/min inlet Pressure 16 barg/3 barg
Max/min inlet Temp 49°C / 4°C
Pressure Dew Point 3°C



Hankison HRA & HRB


Capacity 0.5 – 360.3 m³/min
Max/min inlet Pressure 16 barg/3 barg
Max/min inlet Temp 49°C / 4°C
Pressure Dew Point 3°C

Sullair SPE/SPR


Capacity 3.8 – 125 m³/min
Max/min Operating Pressure 9.7 barg/4.4 barg
Max Operating Temp 49°C / 4°C
Pressure Dew Point -40°C

Hankinson HEA HHL/HHE/HHS


Capacity 1.5-152.9 m³/min
Max/min Operating Pressure 9.7 barg/4.4 barg
Max Operating Temp 49°C / 4°C
Pressure Dew Point -40°C

Pure Air PAXW


Capacity 2 – 60 m³/min
Max/min Operating Pressure 10 barg/4 barg
Max/min Operating Temp 50°C / 4°C
Pressure Dew Point -40°C

Sullair SPXW


Capacity 3.8 – 125 m³/min
Max/min Operating Pressure 10 barg/4 barg
Max/min Operating Temp 48.9°C / 4°C
Pressure Dew Point -40°C

Hankinson HPD


Capacity 8.5 – 90.6 m³/min
Max/min Operating Pressure 10.2 barg/4.4 barg
Max/min Operating Temp 48.9°C / 4°C
Pressure Dew Point -40°C

Pure Air PAXJ


Capacity 3 – 150 m³/min
Max/min Operating Pressure 10 barg/4 barg
Max/min Operating Temp 50°C / 4°C
Pressure Dew Point -40°C

Sullair DBP


Capacity 500 – 1000 cfm
Max/min Operating Pressure 9.7 barg/4.4 barg
Max/min inlet Temp 50°C / 4°C
Pressure Dew Point -40°C

Hankinson HBP


Capacity 14.2 – 122 m³/min
Max/min Operating Pressure 9.7 barg/4.4 barg
Max/min Operating Temp 50°C / 4°C
Pressure Dew Point -40°C

Pure Air PAXB


Capacity 15 – 200 m³/min
Max/min Operating Pressure 10 barg/4 barg
Max/min Operating Temp 50°C / 4°C
Pressure Dew Point -40°C

Sullair MPF/MPH



Capacity 1 – 468 m³/min
Air Quality Partikel Solid 0.01 micron
Oil 0.01 ppm

Hankinson AF/NGF


Capacity 1.98 – 45.3 m³/min
Air Quality Partikel Solid 0.01 micron
Oil 0.01 ppm

Pure Air PAG


Capacity 1 – 468 m³/min
Air Quality Partikel Solid 0.01 micron
Oil 0.01 ppm

AIR SEPARATION

Model Can Gas CAP
Capacity 5 – 300 Nm³/H
Purity 99 – 99.99%

CANGAS® PSA nitrogen generator units can produce 95% to 99.999% purity of nitrogen with capacities up to 5,000 Nm3/h. Users can produce nitrogen gas on actual demand from dry compressed air directly with low running cost. CANGAS® PSA nitrogen generator offers a more economical, more reliable and more convenient nitrogen gas solutions than nitrogen gas cylinders and bulk nitrogen.

Model Can Gas CAPO
Capacity 5 – 150 Nm³/H
Purity 93% ± 2%



Economical, low maintenance, and simple method for nitrogen generations especially suitable for low purity from 95%-99.9%.

By PSA principles, CANGAS® CAPO Series high quality PSA oxygen gas generator generate 93±3% purity oxygen gas directly from compressed air. Compared with traditional Bulk liquid oxygen and cylinders oxygen, CANGAS on-site high quality PSA oxygen gas generator can reduce cost down to 50 percentages. They can produce oxygen by your will, overcoming the limits of distance, location and transportation.

Model Can Gas CAM
Capacity 0.9 – 2500 Nm³/H
Purity 95 – 99%



Membrane N2 generator is a high technology gas generation equipment with many advantages, such as more reliable, more convenient, more economic, more flexible, highly integrated, and highly automised. With these advantages, membrane N2 generator is used in wide range of application, namely chemical industry, food industry, beverage industry, pharmaceutical industry, electronics industry and many more.

Model Can Gas CAVO
Capacity 300 – 2500 Nm³/H
Purity 93% ± 2%



When you require air separation solution for a large scale of oxygen production, we have the answer for you. CANGAS® VPSA oxygen generators that use Vacuum Pressure Swing Adsorption (VPSA) to produce oxygen from air directly.

though more complicated than PSA generator,VPSA oxygen generators offers higher efficiency and more economical while oxygen capacity is higher than 200 Nm³/h. Industries served by VPSA oxygen generators include Steel and metallurgy, paper and pulp, mineral leach, furnace, etc.

Model Can Gas CAPO C
Capacity 1 – 2 M³/H
Purity 93%

CAPO C series Smart O2 generatos are developed for the small size of health care facilities and commercial applications, especially for low flow rate of O2 usage, a stand alone system with highly compact, plug and run design and versatile adaptability the C series SMART O2 system is excellent in performance, stability and convenience.
